Bulk material simulation in CAD
Design
Algoryx Momentum Granular combines Multibody System Dynamics (MBSD) with Nonsmooth Discrete Element Models (NDEM) simulations in a powerful CAD interface. It lets you easily design complex machines that handle bulk material.
Analyze
With strong coupling between mechanical systems and granular matter, simulations are more stable and have much higher performance as well as accuracy than competing solutions. Your results are much more reliable, much closer to reality.
Optimize
With python scripting you can design advanced controllers and monitors. An extensible library of post-processing, analysis, visualization and data exporting tools, enables you to optimize material flow and understand load distribution in details.
Full system dynamics with granular matter
The dynamics and behavior of granular matter is intricate, especially when coupled to machinery. The stakes involved in a design are high indeed. Small improvements can mean enormous savings in time and energy consumption as well as improvements in quality.
As an extension of Algoryx Momentum, you can easily design your mechanical system such as a feeder, a dump truck, a pelletizing drum or an excavator in full details, without compromise. Then, add bulk material and simulate everything with confidence.
NDEM and multibody
With Momentum Granular, adjust parameters such as size, contact stiffness, friction, rolling friction, and even adhesion. With the latter, you can simulate sludge for instance. At that point, you are ready to simulate and the high performance solver will use all your cores to deliver results quickly.
The NDEM simulation method used is directly integrated with the core AGX MBSD and this is much more stable and much faster than standard DEM solutions. In particular, reaction forces between granules and rigid bodies are accurate.
The power of scripting
With the python interface your can introduce controllers of any complexity which execute at each step, and gather and analyze data on during the simulation.
Analysis
There is also extensive support for post-processing both for quantitative analysis and visualization. The simulation data can be exported so you can use your favorite analysis tools.
With KeyShot export, you can produce stunning videos and that is a very effective way to communicate with your team and decision makers. Depending on system size, you can import your work into an interactive 3D environment such as Unity 3D and Unreal Engine. Step-by-step replay allows you to look from all angles.
Algoryx Momentum Granular is a SpaceClaim plugin providing an interface to strongly coupled MBSD and NDEM simulations with AGX Dynamics. and the AGX Granular module.
It allows for designing complex machines that handle granular matter and tools to optimize performance and material flow.
It is user-friendly so you don’t have to be a simulation specialist.
- Integrated MBSD and NDEM
- High performance solver
- Load analysis and full system dynamics
- Python for controllers
- Post-processing tools and data export
Use case examples
Flexible bucket conveyors
Dynamical vibratory feeders
System level dynamics
Control systems
Pellet screens
